Sanitary Stainless Steel Y Strainer for Liquid Filtration

Sanitary stainless steel Y strainer with removable perforated basket for inline liquid filtration. Available in SS304/316L with multiple sanitary connections, 50–300 μm ratings and serviceable construction.

Richiesta di informazioni
Condividi il tuo amore
Categoria: Tag: , ,

This stainless steel sanitary Y strainer uses a removable perforated basket positioned in an angled branch to capture solid particles from process liquids while allowing routine inspection and cleaning. SS304 and SS316L construction, sanitary connection options and stainless steel strainer elements are consistent with established hygienic filtration equipment used to protect pumps, valves, meters and other downstream components.

Available configurations include 1″–4″ sanitary connections, 50–300 μm filtration ratings, interchangeable gasket materials and mirror-polished or electropolished surface options. The removable threaded cover provides access to the basket without dismantling the complete pipeline, making this Y strainer suitable for industrial filtration solutions where sanitary construction, solids removal and maintainability are important sourcing considerations. Hygienic strainer manufacturers commonly use 316L wetted construction, Tri-Clamp connections and serviceable screening elements for comparable process applications.

Sanitary Y-Type Basket Strainer (8)

Sanitary Y-Type Basket Strainer (1)

Tipo

Sanitary Y-Type Basket Strainer
Materiale

Material: SS304 / SS316L Stainless Steel
Elemento filtrante

SS304 / SS316L Perforated Basket with Optional Stainless Steel Mesh
Grado di filtrazione

50–300 μm
Connessione

Sanitary Tri-Clamp, Weld or Threaded Sanitary Connection
Connection Size

1", 1.5", 2", 2.5", 3", 4"
Pressione di esercizio

Max. 145 psi (10 bar)
Temperatura di esercizio

Max. 248°F (120°C), Depending on Gasket and Operating Medium
